The M5 Pulley Without Bearing is a specialized component of YANTAI XINYANG ELECTRONICS’ M5 Jacquard Module Parts line, designed exclusively for M5-series jacquard looms—the most widely used high-performance looms in the global textile industry. As China’s largest manufacturer of M5 Staubli-compatible jacquard modules, the company leverages 20+ years of expertise to create a pulley optimized for cost-effectiveness and low maintenance.
| Quantity: | |
|---|---|
Produced in ISO 9001-certified workshops in Yantai ETDZ and Fushan District, the pulley undergoes 100% dimension inspection to meet the demands of 500+ textile mills across 10 countries. It is tailored for customers seeking lightweight, low-maintenance solutions for medium-speed weaving applications (≤1,200 rpm).
Specification Category | Details |
Material | Pulley Body: Reinforced PA66+GF30 (glass fiber-reinforced for impact resistance); Surface: Anti-static coating |
Dimension Specifications | Outer Diameter: 25mm±0.03mm; Inner Diameter: 8mm±0.02mm; Thickness: 10mm±0.02mm |
Mechanical Performance | Dynamic Load Capacity: 30N; Static Load Capacity: 45N; Wear Resistance: ≤0.01mm wear after 5,000 hours |
Working Conditions: -20℃ to 85℃ temperature range; 95% RH (non-condensing) humidity resistance.
Anti-Static Rating: 10⁶–10⁹ Ω, preventing static buildup in synthetic fabric production.
Certifications: RoHS 2.0 certified; ISO 9001 manufacturing process; compatible with Staubli M5 jacquard modules.
Production Capacity: Annual output: 2,000,000+ units; Sample lead time: 1–2 days; Bulk lead time: 3–7 days.
Reduced Maintenance: Eliminates bearing-related tasks (e.g., lubrication, replacement), saving 15+ hours of annual maintenance per loom.
Lightweight & Energy-Efficient: 30% lighter than M5 pulleys with bearings, reducing loom energy consumption by 12%.
Cost Savings: 25% lower price than bearing-equipped M5 pulleys, ideal for budget-conscious customers or medium-speed operations.
High Wear Resistance: Reinforced PA66+GF30 material withstands abrasion from textile fibers, ensuring 8,000+ hours of service life (on par with bearing-equipped alternatives).
Anti-Static Protection: Special surface coating prevents static buildup, which can attract fiber dust and cause loom jams—critical for weaving polyester, nylon, and other synthetic fabrics.
Precision Compatibility: Micron-level dimension tolerance ensures a tight fit with M5 jacquard module shafts, reducing vibration and noise to ≤60dB during operation.
Ideal for looms producing home textiles (e.g., bed sheets, tablecloths) operating at 800–1,200 rpm, balancing efficiency and cost without sacrificing performance.
Anti-static coating prevents dust accumulation on automotive seat fabrics, ensuring consistent quality for high-end car brands that require defect-free textiles.
Emerging Market Weavers: Cost-effectiveness and low maintenance make it accessible for small-to-medium enterprises (SMEs) in developing countries, supporting their adoption of M5 loom technology.
Textile Equipment Repairers: Lightweight and easy to install, it reduces repair time for M5 jacquard looms—critical for meeting tight production deadlines.
Compatible with YANTAI XINYANG’s M5 jacquard modules and third-party M5 systems, serving as a standardized component for loom manufacturers seeking reliable, low-cost parts.
Provides free sample pulleys for customers to test with their M5 looms, ensuring perfect integration before bulk orders—avoiding compatibility issues post-purchase.
Digital Maintenance Guides: Offers detailed manuals (English, Spanish, Arabic) on pulley installation, cleaning, and troubleshooting, available for download via www.xinyang999.com.
Online Tutorials: Hosts video guides for maintenance teams, covering best practices for pulley care and replacement.
